MV LIBERTY HARVEST | MV LIBERTY HARVEST
IMO
9418975
Flag
Liberia / MONROVIA
Built
2009
Call Sign
5LOL2
Class
Rina
Shipbuilder
Qingshan Shipbuilding Industry Co
LOA
166.15 m
LBP
156 m
Draft Summer SW
9.50 m
Beam o.a. (Hull)
22.9 m
Air Draft (Keel)
45.62 m
Deck Dimensions
113.30 × 18.0 m
DWT
About 18,388.50 mt
GT / NT
15,549 / 6,089
Bale Capacity
23,960 m³
Container Capacity
TEU 1,023 @ 14ts
Tanktop
18.0 mtons/m²
Pontoon Covers
8.00 mtons/m²
Hatch Covers
5.00 mtons/m²
Number of Holds
2
Tweendeck – Hold 1
25.20 × 13.10 m
Tweendeck – Hold 2
86.10 × 18.00 / 13.10 m
Lowerhold – Hold 1
25.20 × 13.10 / 8.00 m
Lowerhold – Hold 2
86.10 × 18.00 / 13.10 m
Tweendeck Heights
Hold 1: 2 / Hold 2: 4
Main Deck Hatches
2
Floor Space (Deck)
1,972 m²
Floor Space (Under)
3,557 m² + + 6 extra panels
Main Cranes
2 × 400 mt NMF
Combined Lift
Up to 800 mt SWL
Auxiliary Crane
1 × 120 mt NMF
Auxiliary Hoist
2 × 40 mt
Machinery
MAN 7L 58/64 9.800 kW
Aux. Engines
Caterpillar, 3 × abt. 600 kW
Bowthruster
1 × 800 kW
Speed
About 13 Knots
Heavy Fuel Oil (HFO)
1,570 m³
Diesel Oil (MDO)
235 m³
Fresh Water
192 m³
Type Description
Heavy Lift Multipurpose Dry Cargo Vessel. Fitted for the carriage of dangerous goods of all IMO classes. ICECLASS 1A
Special Features
IMO / Grain / CO2 / ITF Fitted · Stability Pontoons · Adjustable Bulkheads in Multiple Positions
